The aircraft can also be adapted to support missions that require a longer endurance. The VTOL part of the system can easily be removed, providing users with a fully functional fixed wing system.
With a flight endurance from 8 to 16 hours, the AR3 VTOL is highly transportable, requires a very small logistics footprint, and is interoperable with Tekever’s family of systems. Its proven dependability, versatility, and low operational costs, make the AR3 VTOL the perfect choice for ISTAR and/or Commercial Operations
HOT-SWAPPABLE VTOL
TEKEVER AR3 VTOL is our small, long endurance UAS designed to support a wide range of demanding land and maritime operations. The addition of VTOL capability increases its flexibility of deployment and reduces the logistics package. TEKEVER AR3 VTOL is also the smallest UAS in the market to feature a high-performance, dual side-looking SAR.
MODEL
OVERVIEW
Wingspan
3.5m
Length
1.9m
MTOW
25kg
Payload Capacity
4kg
Flight Endurance
VTOL: 8 hours/Fixed: 16 hours
Service Ceiling
3,600 m AMSL
MODEL OVERVIEW
Comms Range
100km
Cruise Speed
75-90km/h
GCS
Common GCS with AR4, AR3 and AR5. Supports multiple operators and aircraft
Launch Method
VTOL or Catapult
Recovery Method
VTOL or Parachute/Net/Belly/Water
Vehicle Integration
System transport GCS
Technical
Data
- Lowest total cost ownership
- ITAR Free
- Easy launch & retrieval
- ISTAR Missions
- Wide Area Surveillance
- Border Protection
- Maritime Surveillance
- Communications Relay
- Pollution Monitoring
- infrastructure Monitoring
- Reduced logistics footprint, configured for the most demanding tactical scenarios
- Extremely easy to assemble, operate and store, assuring excellent readiness conditions
- Launched with a mobile catapult system, that can be easily transported and used
- All terrain retrieval using deployable parachute and airbags for sensor protection
- Real time collection, processing and transmission of high definition video from multiple EO and IR sensors
- Optional BLOS datalink available, allowing for extended range operations
- Wide range of payload and sensor options according to each missions specific requirements
